With a reputation of product excellence and reliability, BCF offers its customers a wide range of high quality, soft annealed, single/double layer, plain and plastic coated copper coils for diverse applications. These tubes are manufactured with an outside diameter tolerance of +0.0/-0.08mm (0.003"), annealed at approximately 600°C, giving a hardness range of 45/60 HV5. Our smooth bore copper tubes are characterized by their bright, clean and dry internal and external surfaces. Superior dimensional control offers a trouble free performance and cost saving. The tube ends are capped at both ends to maintain the standard of cleanliness.
BCF manufactures high quality plastic coated copper coils, copper alloy coils designed for protection against aggressive environment and colour coded to aid identification.
Standards
Phosphorus deoxidized copper (DLP)
standard
ASTM B –75
BS 2871
JIS H 3300
DIN 1787
symbol
C 12000
C106
C 1201
SW-CU
Phosphorus deoxidized copper (DHP)
standard
ASTM B-68
BS 2871
JIS H 3300
DIN 1785
symbol
C -12200
C 106
C 1220
SF-CU
Tough Pitch Copper (ETP)
standard
-
BS 2871
JIS H 3300
DIN 1787
symbol
C 11000
C 101
C 1100
ECU 58
Dimensional Range
Outer Diameter - 3.15 mm to 22.00 mm
Wall Thickness - 0.45 mm and above.
Available in length between 5 meters and 30 meters.
Available in single / double layer to match the requirement.
Other Features
Characterized by a bright, clean and dry outside and inside surface.
Delivered with close ends to guarantee high internal cleanness.
Available with pvc coating of blue, black or yellow colour with pvc thickness of 0.50 mm or 1.00mm.
Can be hand straightened or bent as required using standard benders.
End Applications
Refrigeration and air conditioning, oil and gas lines and general engineering applications.
